ROCKWOOL · Marine Insulation

Aktiivinen

SeaRox SL 480

SeaRox SL 480 is a strong, rigid stone wool slab (board) primarily suited to the production of marine panels, as a slab or cut into lamellas, and to floating floors with a pressure-equalising plate of steel or moulding material where higher load capacity is required. Nominal density 200 kg/m³, thermal conductivity 0.037 W/mK, compressive strength ≥ 40 kPa. Complies with MED 2014/90/EU and IMO 2010 FTP Code: non-combustible (MED certificate MEDB00001Z8) and part of the DNV-approved "Steel Deck A-60 floating floor" build-up (MEDB000016G): 60–100 mm SeaRox in one or two layers of equal thickness under two bonded 1.5 mm steel plates. Neutral glass tissue (TN) facing on request. Slabs 600 × 1000 mm in 30 and 50 mm. Supplied by Trivaro.

Artikkelinumerot (2)
115959 116010

Tunnetaan myös nimellä: SeaRox SL 480, SL 480, SeaRox 480, Rockwool SeaRox SL480, marine panel insulation

Marine Deck Coverings / Marine Insulation Sarja: searox

Thickness

30.00, 50.00 mm

Format

Slab

Sizes

600×1000 mm

Fire Class

Non-combustible (IMO 2010 FTP Code Part 1)

Installation

Loose-laid with staggered joints under bonded steel top plates; cut into lamellas for panels

Material

Stone wool slab (board), rigid

IMO

Certified

Sertifikaatit ja vaatimustenmukaisuus

Fire Class Non-combustible (IMO 2010 FTP Code Part 1)

Tuotekuvat (1)

Saatavilla olevat vaihtoehdot

Variantit (2 varianttia)

SKU 115959 — ROCKWOOL SeaRox SL 480, Slab 600×1000 mm

115959
30 mm · Slab 600×1000 mm
In Stock
Add to Inquiry

SKU 116010 — ROCKWOOL SeaRox SL 480, Slab 600×1000 mm

116010
50 mm · Slab 600×1000 mm
In Stock
Add to Inquiry

Tekniset tiedot

Spesifikaatiot

Density kg M3 200
Compressive Strength Kpa 40
Width cm 60
Length cm 100
Surface Per Pallet 30 mm: 96 · 50 mm: 57.6 m²
Material Stone wool slab (board), rigid
A60 Rated Yes
Fire Class Non-combustible (IMO 2010 FTP Code Part 1)
A60 Build Up Steel deck + 60–100 mm SeaRox SL 480 in 2 layers of equal thickness (2 × 30 or 2 × 50 mm, staggered joints) + 2 × 1.5 mm steel plates bonded with adhesive
A60 Certificate No MEDB000016G rev.1 (DNV, Steel Deck A-60 floating floor, valid to 2027-02-20)
Sound Absorption αw = 0.75 (50 mm, unfaced, directly mounted, ISO 354 / ISO 11654)
Thermal Conductivity 0.037
Reach Stone wool complies with Note Q, Regulation (EC) No 1272/2008
Med Certificate No MEDB00001Z8 rev.17 (DNV, non-combustible, valid to 2028-02-15)
Installation Method Loose-laid with staggered joints under bonded steel top plates; cut into lamellas for panels
Facing Plain (unfaced); neutral glass tissue (TN) facing on request
Standard EN 12667 / EN 1602 / EN 826 / EN 1609 / EN ISO 29767
IMO Certified Yes
Organic Content % 2.5
Water Absorption kg M2 < 1 (EN 1609 / EN ISO 29767)

Lataukset

Dokumentit ja sertifikaatit

SeaRox SL 480 — Product Data Sheet (ENG, SEN-00-1-004, 01-12-2023)

Product Datasheet

MED EC-Type Examination Certificate MEDB00001Z8 rev.17 — Non-combustible materials (DNV)

Fire Certificate

MED Certificate MEDB000016G rev.1 — Steel Deck A-60 floating floor (DNV)

Certificate
